VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane

No.1601581609801
Variations
Edit selections
model number: VAX 5330 EEE V3.0 Short Shaft
VAX 5330 EEE V3.0 Short Shaft
compatible model: short shaft
short shaft
type: 220KV
220KV
260KV
Select variations and quantity
model number: VAX 5330 EEE V3.0 Short Shaft
VAX 5330 EEE V3.0 Short Shaft
compatible model: short shaft
short shaft
type: 220KV
The min. inquiry quantity is 0. Add 0 more to continue.
220KV
-
260KV
-
Subtotal
-
  • VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane
  • VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane
  • VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane
  • VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane
  • VAX 5330 (short Shaft) EVTOL Airplane Drone Motor for Fixed Wing Airplane

Description

Key attributes

Material
Stainless Steel
brand name
MAD
place of origin
Jiangxi, China
Product name
VAX 5330 (short shaft) EVTOL Airplane Drone motor
Keyword
brushless motor
Color
as picture shown
Size
D: 62.5 x 67.6mm
Nominal voltage
12S lipo battery
Propeller Mounting Holes
D:31 M3x4,D:20 M3x4
Motor Mounting Holes
D:30 M4x4, D:44 M4x4
Disruptive test
500V
Cable Length
150 mm (Silicone wire)
Function
Unmanned Aerial Vehicle System

Packaging and delivery

Selling Units
Single item
Package size per batch
11X11X6.5 cm
Gross weight per batch
0.600 kg

Product descriptions from the supplier

Warning/Disclaimer
Compliance Reminder for Prohibited and Restricted products
Products Description

MAD VAX 5330 EEE V1.0 (short shaft)

1. Designed for EVTOL, AIRCRAFT, XCLASS to carry 8-10 kg, supports 12S voltage.

2. For long range flight. It also retains the excellent features and characteristics of the previous generation and improves the safety and durability of the motor, which fully meets the demanding requirements of various industries.
Test Benchmarks
Specifications
Model
MAD VAX 5330 EEE V1.0 (short shaft)
RPM
220KV
260KV
No Load Current
1.35A / 30V
1.6A / 20V
Max Thrust
11.2 kg
12.8 kg
Max Current
70.8 A
97 A
Max Power
3263W
4377W
Max Torque
3 Nm
3.5 Nm
Motor Weight
553 g
547 g
Nominal voltage
12S lipo battery
12S lipo battery
Motor Size
61.1 × 84mm
61.1 × 84mm
Recommended Propellers
18x12, 19x10, 20x10, 17x8
18x12, 19x10, 20x10, 17x8x3
Recommend Configuration
